BLUM SERVO-DRIVE - SERVO-DRIVE Sensor and COMBOX Technical Data

29
F
Reset Motion
Reset Wireless
E
EN
Replacing the SERVO-DRIVE switch battery
Cover cap assembly
Press the <Reset Motion> button using a pen (at least 3 seconds) until
the LED flashes quickly.
Press the <Reset Wireless> button using a pen (at least 3 seconds)
until the LED flashes quickly.
Resets the reference run and enables a new reference run to be
started.
Deactivates all functions: All active SERVO-DRIVE switches for the
respective drive unit are deleted.
➢ Open the SERVO-DRIVE switch and
remove the battery
➢ Insert the new battery (type CR2032)
and close the SERVO-DRIVE switch –
note correct polarity +/-
When the battery power begins to weaken, the battery display (LED) begins to flash red
➢ The SERVO-DRIVE switch battery must not be recharged or thrown into fire.
NOTE
