BLUM SERVO-DRIVE

23
EN
Cable diagram
Transformer unit housing for panel fixingTransformer unit housing for base fixing
Sink cabinet
Transformer unit housing for base fixing Transformer unit housing for panel fixing
Upper attachment bracket

SERVO-DRIVE for AVENTOS
Back cabling
Upper cabling
➢ Only 1 Blum transformer can be connected to each distribution cable.
