27
C
1
3
2
4
5
EN
Activating synchronisation
Up to three drive units can be synchronised allowing them to move
simultaneously. This function is required for several cabinets with a
uniform front.
Activating the SERVO-DRIVE switch → see A 1–3.
Press the <SYNC> button for the first drive unit
until the LED flashes green.
Press the <SYNC> button for the second drive unit
unit the LEDs of both synchronised drive units light up green.
Repeat procedure C 2–3 for all additional drive units.
Carry out reference run → see B 1–4.
Operation Lights up continuously Flashes
If there is an activation error, reset all drive units
→ see Reset wireless F 1.
NOTE
Re-activate the SERVO-DRIVE switch, synchronisation and the refer-
ence run → see A 1–3, C 2–4 and B 1–4.
