Turn the key 1 to position
OPEN.
Pull the grey release leaver 2
(OPEN) all the way up and sim-
ultaneously open the case lid.
Closing cases
with touring cases
OA
Turn the key 1 to position
OPEN.
Press catches 2 of the case
lid into retainers 3. Check that
nothing is trapped between the
lid and the case.
Pull the grey release lever 4
(OPEN) all the way up and sim-
ultaneously open the case lid.
The lid engages with an aud-
ible click.
Turn the key 1 in the case lock
so that it is parallel with the
direction of travel and remove.
Removing cases
with touring cases
OA
Turn the key 1 to position RE-
LEASE.
10
132
z
Accessories
