Instrument panel
1 Warning and telltale lights
( 20)
2 Speedometer
3 Function key
4 Multifunction display
( 21)
5 Function key
6 Ambient-light brightness
sensor (for controlling the
brightness of the instru-
ment lighting)
with alarm system
(DWA)
OE
Alarm system LED
with on-board com-
puter
OE
Telltale light for engine
rpm warning ( 76)
7 Rev. counter
2
18
z General views
