10 Coolant temperature
display
11 No standard equipment
with on-board com-
puter
OE
Gear indicator; "N" indic-
ates neutral
12 Fuel level ( 33)
13 Values area for status in-
dicator ( 42)
14 Warning symbol ( 22)
15 Trip meter ( 42)
Warnings
Mode of presentation
Warnings are indicated by the
corresponding warning lights.
Warnings that do not have warn-
ing lights of their own are indic-
ated by 'general' warning light 1
showing in combination with a
text warning or a warning sym-
bol in the multifunction display.
The 'general' warning light shows
yellow or red, depending on the
urgency of the warning.
In addition, the warning triangle 3
can also be displayed next to the
values area 2. These warnings
appear in alternation with the
odometer readings ( 42).
The status of the 'General' warn-
ing light matches the most ur-
gent warning.
The possible warnings are listed
on the next pages.
3
22
z
Status indicators
