Threaded fasteners
Front wheel Value Valid
Brake caliper on telescopic fork
M10 x 65 38 Nm
Clamp of quick-release axle
M8 x 35 Tighten screws six times in alternate
sequence
19 Nm
Screw in front-wheel quick-re-
lease axle
M20 x 1.5 50 Nm
Rear wheel Value Valid
Locknut of the final-drive chain
tensioning screw
M8 19 Nm
Rear quick-release axle in
swinging arm
M16 x 1.5 100 Nm
12
145
z
Technical data
