Brakes
Front wheel
Type of front brake Hydraulically, radially actuated Brembo Racing
two-rotor disc brake; floating, supported Racing
brake discs; 4-piston monobloc fixed caliper with
titanium pistons
Front brake pad material Sintered metal, mixture Z04
Front brake-disk thickness 0.27 in (6.75 mm), New
min 0.25 in (min 6.25 mm), Wear limit
Rear wheel
Type of rear brake Hydraulically actuated Brembo Racing single-disc
brake, 4-piston fixed caliper with titanium pistons
Rear brake pad material Sintered metal, mixture H38
Rear brake-disk thickness 0.16 in (4.0 mm), New
min 0.14 in (min 3.5 mm), Wear limit
Blow-by clearance of footbrake lever 0.08 in (2 mm), between eccentric and stop
12
168
z Technical data

BMW HP4 RACE Specifications

General

Displacement	999 cc
Torque	120 Nm at 10, 000 rpm
Fuel Capacity	17.5 liters
Seat Height	831 mm
Engine Type	Water-cooled inline 4-cylinder 4-stroke engine, four titanium valves per cylinder, BMW ShiftCam
Power	215 hp (158 kW) @ 13, 900 rpm
Transmission	6-speed
Frame	Carbon fiber
Weight	171 kg (dry)
Front Suspension	Öhlins FGR 300 upside-down fork
Rear Suspension	Öhlins TTX 36 GP
Brakes	Brembo GP4 PR monoblock calipers, dual 320 mm discs (front), Brembo 4-piston caliper, single 220 mm disc (rear)
