Settings can be entered in the Park menu.
Toolbar, right
The parking assistance functions are displayed in
the right toolbar:
▷ Status of the parking assistance systems.
▷ Available parking methods of the Parking Ma‐
noeuvre Assistant.
▷ Functions of the Reversing Assistant.
▷ Functions of the Manoeuvre Assistant.
▷ Additional information in case of malfunc‐
tions.
Park Distance Control PDC
Principle
Park Distance Control PDC assists with parking.
Obstacles in front of or behind the vehicle are
signalled by acoustic and visual warnings.
Obstacles that are detected by the side ultra‐
sonic sensors can also be reported.
General
The range of the system is approximately 2 m,
6 ft, depending on the obstacle and environmen‐
tal factors.
An acoustic warning is given when the vehicle is
approx. 70 cm, 27 in away from an object and a
collision is imminent.
For objects behind the vehicle, the acoustic
warning is given sooner, at a distance of approx.
1.50 m, 5 ft.
In addition, the PDC display is displayed in the
Assisted View in the central display area of the
instrument cluster.
Safety notes
WARNING
The system does not relieve you of your per‐
sonal responsibility to assess the traffic situa‐
tion correctly. Due to system limitations, it can‐
not respond independently and appropriately in
all traffic conditions. There is a risk of accident.
Adapt your driving style to the traffic conditions.
Observe the traffic situation and intervene ac‐
tively if the situation warrants it.
WARNING
Approaching at high speed when using Park
Distance Control PDC may result in late warn‐
ings, due to the physical conditions. There is a
risk of injury or material damage. Avoid ap‐
proaching an object at speed. Avoid moving off
at speed while Park Distance Control PDC is
not yet active.
Overview
Sensors
The system is controlled using the following sen‐
sors:
▷ Ultrasonic sensors in the front/rear bumpers.
▷ Side ultrasonic sensors.
Turning the PDC on/off
Turning on the system automatically
The system switches on automatically in the
following situations:
▷ When the drive-ready state is turned on when
engaging selector lever position R.
▷ When approaching detected obstacles, if the
speed is below approximately 4 km/h,
2.5 mph. The distance from the obstacle at
which the system activates depends on the
individual situation.
Seite 253
Parking
CONTROLS
253
Online Edition for Part no. 01405A38CB9 - VI/21
