BMW X5 (E53) LHD - Page 13

EN/11
6. To prepare the module holder in the instrument panel
for the installation of the on-board monitor
Place the bottom on-board monitor holder (5)
into the cut out radio module holder (40) (push it
right to the back).
Mark the five mounting points (41) and remove
the bottom on-board monitor holder (5) again.
Carefully drill the marked mounting points (41) in
the radio module holder (40) with an angled drill
using a 2.4 mm drill bit.
When drilling the holes ensure that you do
not damage the instrument panel.
F 53 0720 B
40
41
5
F 53 0721 B
40
5
6
7
4
F 53 0722 B
40
41
Insert the bottom on-board monitor holder (5),
place the spacer plate (6) on to the bottom on-
board monitor holder (5) and secure both to the
radio module holder (40) using five plastic
screws 3.5x10 mm (7) using a torque of 1.5 Nm.
Place the top on-board monitor holder (4) into
the cut out radio module holder (40) (push it right
to the back).
Mark the three mounting points (41) from below
and remove the top on-board monitor holder (4)
again.
Carefully drill the marked mounting points (41) in
the radio module holder (40) with an angled drill
using a 3.5 mm drill bit.
Then slightly countersink the three holes from
above.
4
F 53 0723 B
40
8
Insert the top on-board monitor holder (4) and
secure it to the radio module holder (40) using
three self-tapping screws 3.5x6.5 mm (8) using a
torque of 2 Nm.
Retrofit/Installation kit No. 65 90 0 025 169 Issue date: 10.2001
Installation instructions No. 01 29 0 030 090
