EN/22
11. Coding and concluding work
If the video module and the TV amplifier forTV function are also installed in the car, the
coding and concluding work is not to be completed until after the video module and the TV
amplifier forTV function have been installed (see section 12 for a description of the
connections forTV function).
Coding
This system requires coding.
To ensure that the retrofit system
– functions in full and
– operates perfectly with the other systems in the car and prevents malfunctions and errors,
this retrofit system must be coded and it may also be necessary to code other components
in the car.The codes are then saved in the central code key of the IKE.
This coding process is automatic using the current coding program in the "Retrofit" path.
The procedure is user-guided, simply follow the text instructions for completing the various
steps.
Procedure
– Connect the DIS/MoDIC to the car
– Switch the ignition "ON"
– Select "Coding ZCS"
– Enter the date and confirm with "Y" (MODIC only)
– Series "E53"
– Path: "2 Retrofit"
– System: "Navigation"
The current "Navigation CD-ROM operating software V16" is required to load the
operating system.
Important. Do not insert the "Operating software V16" CD-ROM into the CD drive yet.
Do not insert the "Operating software V16" CD-ROM into the CD drive until you are asked to
do so in the instruction texts on the on-board monitor.
At the same time this "Operating software" CD-ROM completes the language coding.
– Start the automatic coding (confirm by pressing "Y")
– Follow the instructions on the on-board monitor.
– Print out the new central label for the amended coding key and affix it to the car on the
right-hand side of the boot near the battery.
– After the message "Coding complete" appears on the monitor of the DIS/MoDIC, switch
"OFF" the ignition, wait for at least 10 seconds and then switch the ignition "ON" again
– Print out the error memory
– Insert the "Road map" CD-ROM into the navigation computer
– Conduct a function test
