Step 1 Building the G20U Bearing Assemblies.

NOTE: the Bearing Assembly Order: M6 x 35

Machine Screw (H95), SG20U Bearing(H44) with

hub facing toward the Bearing Fender Washer

(H42), Eccentric Washer (H41), Eccentric Spacer

(H40), M6 Locknut (H18).

When inserting the Bearing Assembly

through the Back Frame (QZ1) make sure

the Hub of the G20U Bearing faces the

Bearing Fender Washer which is pressed

against the wood.
