BOGE Operating instructions trinity Page 9
General 1.5 Brief operating instructions
1.5 Brief operating instructions
Set pressure range
1. Use arrow key(s) / to display Software-Version (BOGE V x).
2. Press ENTER key
→ a three digit number, of which the first number
flashes, appears in the place of the software version.
3. Use arrow keys / to input the first place (3) of code 360.
4. Press ENTER key
→ the second number of the three digit number
flashes in the place of the first.
5. Use arrow keys / to input the second place (6) of the code.
6. Press ENTER key
→ the third number of the three digit number flashes
in the place of the second.
7. Press ENTER key to acknowledge the third place (0) of the code
→
corresponding to the selected code, the parameter display (P<xx.xx>yy.yy
bar) appears with a flashing value xx.xx.
8. Use arrow keys / to bring the upper pressure value to the desired
value, use ENTER key quit
→ now the right number blinks (yy.yy).
9. Use arrow keys / to bring the lower pressure to the desired value and
then use ENTER key to quit
→ now the display ‚Pressure Target Val-
ues’ appears. – All other (those in between) pressure switch points are
automatically calculated by the microprocessor.
Set number of
compressors and
interval period
‚Priority Change’
1. Input Code 832, as already described → For example: 3 x 002h, appears
in the display, whereby the left number (here ‚3’) blinks.
2. Use arrow keys / to set the number of compressors to be consid-
ered, then use ENTER key to quit
→ now the right number blinks (here
‚002’).
3. Use arrow keys / to set the priority change interval time to the
desired value and then use ENTER key to quit
→ the display changes
according to the following criteria:
– If the selected interval time is greater than zero, the display ‚Pressure
+ Time to next priority change’ appears.
– otherwise a ‚Switching Times’ appears - for further steps when using
the timer see functional description.
