BOGE Operating instructions trinity Page 1
General 1.1 General safety instructions
Part 1: General 1.1 General safety instructions
Safety instructions
for operating
the control unit
1. The control unit may only be put into operation after these instructions
have been read and properly understood.
2. The control unit may only be used for the purpose described in these
instructions.
3. The user/owner must ensure
– that only trained and and authorised staff use the control unit.
– that the operating personnel are thoroughly familiar with and follow all
safety instructions.
– that the control unit is only used in a safe operating condition.
4. The unit may only be used with the options recommended or approved by
the manufacturer.
5. The unit may never be used if one or more parts are damaged, not oper-
ating correctly, or if damage can be seen or is suspected.
trinity integrated into
the compressor
If the control voltage of the compressor is switched off all the other compres-
sors (electrically connected to the trinity) are released at the same time.
Exception „Pressure
sensor inside
compressor switch
cabinet“
Normally the separately shipped pressure transmitter of the trinity is installed
directly to the central compressed air receiver of the compressed air network.
Should, as an exception, the pressure transmitter of the trinity be installed in
the switch cabinet of the compressor (like the compressor pressure transmit-
ter) and not on the external receiver, the following steps are to be observed: If
the compressor with the integrated trinity is shut off the compressed air net-
work (e.g by shut-off valve or ball valve) the pressure transmitter can no longer
obtain any information from the compressed air network and all compressors
connected to the trinity are no longer controlled correctly. It is absolutely nec-
essary that the pressure transmitter of the trinity is always impinged with net-
work pressure!
Safety instructions for
repair of the control unit
1. Adjustments, troubleshooting and repairs may only be carried out by
qualified systems electricians (see DIN VDE 0100 or DIN VDE 0113,
EN 60204).
2. Before carrying out repairs:
– switch off the voltage
– check that none of the parts are under power.
Attention!
Non-compliance with the following safety instructions may lead to physical
injury and damage to the control unit. In addition to the instructions in this
manual, the general safety and accident prevention rules must always be fol-
lowed!
