Operating instructions Typ 2200 7 / 32
Betriebsanleitung Typ 2200
2 Technical data of controller and control cabinet
components
2.1 Power components
2.1.1 Supply
Supply L1-L2-L3 direct to 4-pole master switch – Q1 (T1-T2-T3)
2.1.2 Motor control
Motor connection U-V-W direct to motor contactor – K1 (2-4-6)
2.1.3 Power supply
2.1.4 Fuse protection
Primary voltages 0 - 220 V, 380 V, 400 V, 440 V, 500 V, 550
V
Secondary voltages
0 V AC - 230 V AC Valve voltage 230 V AC
0 V AC - 115 V AC Valve voltage 115 V AC
0 V DC - 24 V DC Valve voltage 24 V DC
0 V AC - 20 V AC Control circuit board supply voltage
Fuses in the control cabinet
F1 to F3 each 1 A
Fuses on the control circuit board
Fuse F1 0.8 A T (slow-blow)
Fuse F2 2.0 A T (slow-blow)
