Bollfilter 2200 - Operation; Device functions and control sequence

Operating instructions Typ 2200 9 / 32
Betriebsanleitung Typ 2200
3 Operation
3.1 Device functions and control sequence
Fig. 3-1 Electronic controller type 2200
Fig. 3-2 Display and operating elements
1 Fastening
2 Display and operating elements
3 Housing
4 Master switch
5 Connection
1 Display screen for text display, 2 lines of 16 characters
2 "Alarm" LED (red)
3 "Service" LED (yellow)
4 "Operation" LED (green)
5 Keypad
1
2
3
4
5
1
2
3
4
5
