8 / 32 Operating instructions Typ 2200
Betriebsanleitung Typ 2200
2.2 Control circuit board inputs / outputs
2.2.1 Optocoupler inputs (E1 - E5), terminals 31 - 40
2.2.2 Live relay outputs
NOTE
The connections and designations depend on the type of filter and can be found
in the respective circuit diagrams.
2.2.3 Potential-free relay outputs
NOTE
The connections and designations depend on the type of filter and can be found
in the respective circuit diagrams.
2.3 Circuit diagrams
The circuit diagrams for the controller are contained in the appendix of these
operating and installation instructions.
Outputs VE1 - VN1 to VE3 - VN3 Terminals 8 - 13
Outputs A1 - A15 Messages 1 - 5
(change-over contact)
Terminals 16 - 30
