Fold the lifting hook Ä Fig. 36 up.
Always attach the lifting tackle to the lifting eye to load the
vibratory plate Ä Fig. 37 on a transport vehicle.
Lash the vibratory plate down to the transport vehicle, so that
it is secured against rolling, sliding and turning over. Fasten
the lashing tackle at the marked lashing points.
Fig. 36
Fig. 37
Operation – Loading/transport
BPR 50/55 D / BPR 60/65 D
46
