In the case of frequency inverters of the VCB device series, the following is to be
considered:
The devices feature a common internal interface for communication with the interface
converter RS232-KP100 as well as with the extension boards VCI-232 and VCI-485.
With the interface converter RS232-KP100, it is not possible to use an extension board
VCI-232 or an extension board VCI-485 at the same time. Otherwise, there will be
collisions in the data traffic.
Due to the common internal communication interface
− for remote connection via RS232-KP100 and
− to extension board VCI-232 and VCI-485
the following parameter settings are required for a functionally safe teleservice.
Parameter
No. Description Settings Remarks
10
aud rate
3 – 9600 kBaud Factory setting
395
rotocol type
0 – VCB - Bus Factory setting
Actual value
No. Description Settings Remarks
248
us address
1
Factory setting
Note: When extension board VCI-485 is installed and communication via the
interface converter RS232-KP100 is required at the same time, the Node
ID of the VCI-485 and the Node ID set in the control software VPlus mus
t
be the same!
If the Node ID is not the same, no communication with the frequency
inverter is possible via interface converter RS232-KP100!
1211/07
