9. VERIFICATION OF TEMPERATURE SENSORS
PROBE PT100 (Single point for both the cavity and core probee).
The PT100
PT100
Temperature sensor comprises a resistance sensor with the value of 100 ohms for a temperature of 0°
and 138.5 ohms for a temperature of 100°. The variation of the resistance to temperature relationship is
linear. The resistance reading is directly proportional to the measured temperature. The sensor is not
polarised. The sensor can be extended using copper wire.
Temperature in °C relative to Resistance in Ω
ΩΩ
Ω for PT100 sensor
°C 0 1 2 3 4 5 6 7 8 9
0
100.00
100.39
100.78
101.17
101.56
101.95
102.34
102.73
103.12
103.51
10
103.90
104.29
104.68
105.07
105.46
105.85
106.24
106.63
107.02
107.4
20
107.79
108.18
108.57
108.96
109.35
109.73
110.12
110.51
110.90
111.28
30
111.67
112.06
112.45
112.83
113.22
113.61
113.99
114.38
114.77
115.15
40
115.54
115.93
116.31
116.70
117.08
117.47
117.85
118.24
118.62
119.01
50
119.40
119.78
120.16
120.55
120.93
121.32
121.70
122.09
122.47
122.86
60
123.24
123.62
124.01
124.39
124.77
125.16
125.54
125.92
126.31
126.69
70
127.07
127.45
127.84
128.22
128.60
128.98
129.37
129.75
130.13
130.51
80
130.89
131.27
131.66
132.04
132.42
132.80
133.18
133.56
133.94
134.32
90
134.70
135.08
135.46
135.84
136.22
136.60
136.98
137.36
137.74
138.12
100
138.50
138.88
139.26
139.64
140.02
140.39
140.77
141.15
141.53
141.91
110
142.29
142.66
143.04
143.42
143.80
144.17
144.55
144.93
145.31
145.68
120
146.06
146.44
146.81
147.19
147.57
147.94
148.32
148.70
149.07
149.45
130
149.82
150.20
150.57
150.95
151.33
151.70
152.08
152.45
152.83
153.20
140
153.58
153.95
154.32
154.70
155.07
155.45
155.82
156.19
156.57
156.94
150
157.31
157.69
158.06
158.43
158.81
159.18
159.55
159.93
160.30
160.67
160
161.04
161.42
161.79
162.16
162.53
162.90
163.27
163.65
164.02
164.39
170
164.76
165.13
165.50
165.87
166.24
166.61
166.98
167.35
167.72
168.09
180
168.46
168.83
169.20
169.57
169.94
170.31
170.68
171.05
171.42
171.79
190
172.16
172.53
172.90
173.26
173.63
174.00
174.37
174.74
175.10
175.47
200
175.84
176.21
176.57
176.94
177.31
177.68
178.04
178.41
178.78
179.14
210
179.51
179.88
180.24
180.61
180.97
181.34
181.71
182.07
182.44
182.80
220
183.17
183.53
183.90
184.26
184.63
184.99
185.36
185.72
186.09
186.45
