Page 17 3BE390761NM – 12/11
BONNET GRANDE CUISINE
Registered Office:
Rue des Frères Lumière - Z.I Mitry Compans
F-77292 MITRY MORY Cedex
6. HYDRAULIC DIAGRAMS
The supply hose to the boiler must above the level of the steam outlet to avoid the descale
chemical damaging the solenoid housing.
6.1 6 AND 10 LEVEL PRECISIO OVENS
Flow limiter
Injection
Cooling
Cleaning
L1 L2 L3
Electric
6 GN 1/1
0.25 l/min 1.2 l/min 2 l/min without jacket
Electric 10 GN 1/1
0.5 l/min 1.2 l/min 2 l/min without jacket
Gas 6 GN 1/1
0.25 l/min 1.2 l/min 2 l/min without jacket
Gas 10 GN 1/1
0.5 l/min 1.2 l/min 2 l/min without jacket
Electric 10 GN 2/1
0.8 l/min 1.2 l/min 2 l/min without jacket
Gas 10 GN 2/1
0.8 l/min 1.2 l/min 2 l/min without jacket
