11. FRONT LINE PARTS
D
e
signation
Codes
Drive shaft gasket + wear ring 145587
Complete mounted sensor sub-assembly for oven generator 147060
Complete mounted generator probe (sensor) subassembly for gas oven 147061
Lighting socket sub-assembly + cable 147328
4 way solenoid valve, 3 x 10 L/min + 1 x 5 L/min 147793
Starting electrode 148223
Sub assembly - Gas valve without safety enclosure 148222
Snap-on pushbutton / 2 contact pushbutton 300183 / 300189
Reed switch 300676
Three-pole contactor 230V 50/60 Hz 25A / 32A 300697 / 300698
Three-pole contactor 230V 50/60 Hz 40A / 50A 300699 / 300700
Anti-interference relay 300769
60° C condenser thermostat / Manual resetting 320°C thermostat + nut 301065 / 301066
Pressure switch B1 55/41 301373
PT100 sensor, diameter 4, 350 in length 301456
2 points PT 100 regulating sensor 301471
Gas generator probe 301479
Circular heating element, round flange, 9KW 340 ∅ / 9KW 430∅
302229 / 302232
Circular heating element, round flange, 15KW 500 ∅
302230
6 kW 230V immersion heater with opening for bulb passage 303122
8 kW 230V immersion heater 303127
7.5 kw immersion heater, 380 in length with bulb hole 303129
24 kw immersion heater, 570 in length with bulb hole 303130
17.7 kw immersion heater, 570 in length with bulb hole 303131
Axial fan 304194
16mf motor condenser 304259
Fan motor 304267
Condenser 5 µF for pump 304269
Pump with cylinder blocks 230V 50/60HZ 304275
LN2 fixed centrifugal fan 7000rpm 304276
Peristaltic pump 3 L/h / Internal pump pie work 304279 /
Reducing gear with centre return spring, 85 degrees 305108
Green indicator 230/400V, complete 308334
Halogen bulb 308477
Lighting transformer BT 230V 50HZ 12V 308479
1A fast acting fuse / Fuse 3.15 Amps 309335 / 309407
Encoder 309411
Ribbon cable 309417
Fuse 6.3 x 32 T10 Amps SCHURTER 309506
Led facia card 309515
5 position switch, 8 point connector + 2 wires 309521
3 position switch, 6 point connector 309522
FastPAD 2010 relay card 309578
125 Ma fuse 309612
Safety box 577DBC 310324
Motorised valve 230V 50/60 Hz female ¾ / 1" 314359 / 314360
Pump UP 60-321, rate 150 L/min 314361
10.2 x 15 diameter 2 mm thick metal-asbestos plastic gasket 318033
Heating resistance capacity + immersion heater gasket 366461
Lighting glass sheet gasket 366557
Door stop 366572
Synthetic filter 386087
