13. Attach the camera to the mounting plate by turning the dome camera to the right approx-
imately 15 degrees and locking into place as seen in Figure 2.4.
Fig. 2.4 Attaching the AutoDome Easy to the mounting plate
14. Secure the safety locking screw with the locking torx wrench (T-10) supplied with the
AutoDome Easy.
