8.11 Reference messages on OBD printed circuit board
No. Designation Remedy Chapter
6005 Error group „Fatal“
6006 Error group „Status fault“
6007 Error group „Download fault“
6008 Error group „Communication fault“
6009 Error group „Not supported“ Run interface test 5.1 - 5.4
6010 SST could not be opened Check AMM connecting cable to measuring technology
6011 SST could not be closed using ohmmeter.
6012 Write error on interface Check connecting cable for OBD printed circuit board
6013 Read error from interface to CPU printed circuit board using ohmmeter
6014 OBD module does not respond OBD printed circuit board faulty —> replace 10.30
6017 Function call invalid CPU printed circuit board faulty —> replace 10.27
6018 Interface not open
6019 Unknown error
6030 Unexpected / unknown response
6031 Buffer overrun
6032 Module ID incorrect
6033 CRC incorrect
6034 OBDM parameter missing / wrong
6035 No memory for fault text
8.11.1 Reference numbers for errors in "Fatal" group
No. Designation Remedy Chapter
6050 Internal module error OBD printed circuit board faulty —> replace 10.30
CPU printed circuit board faulty —> replace 10.27
8.11.2 Reference numbers for errors in "Status error" group
No. Designation Remedy Chapter
6060 Faulty CRC16 checksum OBD printed circuit board faulty —> replace 10.30
CPU printed circuit board faulty —> replace 10.27
6061 Level circuit 30 line low Check connecting cable for OBD printed circuit board to CPU
printed circuit board using ohmmeter
6062 Unknown command to OBDM
6063 Invalid command parameter OBD printed circuit board faulty —> replace 10.30
6064 Command not permissible CPU printed circuit board faulty —> replace 10.27
6065 Command not possible in device
6066 Memory overrun at U-lambda
8.11.3 Reference numbers for errors in "Download" group
No. Designation Remedy Chapter
6070 DBoot module not loaded Re-boot BEA if fault
6071 Other module not loaded remains present: Re-install system software 5.23
6072 Date sequence not OK OBD printed circuit board faulty —> replace 10.30
6073 Module combination does not match CPU printed circuit board faulty —> replace 10.27
6074 Download package incorrectly received
6075 Module checksum n. o.k.
