Bosch BEA 150 - Terminal Diagram of Connection Cable for; Terminal Diagram of Temperature Sensor

46
6.1.1 Terminal diagram of connection
cable for clamp-on pickup
6.1.2 Terminal diagram of
temperature sensor
1
2
3
4
5
1
2
3
4
5
B
A
A
B
463430
+-
R1
R2
1
3
2
1
3
2
Ansicht
Lötseite
230036
Resistance test with digital multimeter:
Measured on 3-way amphenol plug, pin 1 to pin 2
R (25°C) = 1005 Ω
+ 5 Ω
R (90°C) = 1530 Ω
+ 12 Ω
View of solder side
