4 Technical specification
4.1 Housing
The CISS is built from a robust, industrially-suited housing with a suitable connector, that can be fixed at the housing via
a fixing bracket.
The compact design of the CISS fits perfectly in different industrial applications and also allows an easy and user-friendly
mounting in difficult to access environments.
For mounting instructions, please refer to chapter 5.1. Mounting the CISS.
4.2 Dimensions
4.3 Device specification
ATTRIBUTE VALUE
Dimension Length 53.2 mm x Width 80.0 mm x Height 21.3 mm
Weight Ciss Device: 34 g
Cable: 60 g
Fastening set (2magnets, 2 screws, 2 washers): 19g
Power supply 5V DC
Enclosure protection class IP 54
Sampling rate (selectable) Depending on the selection of sensor settings (Inertial sensors: ≤100 Hz /
special mode accelerometer: 2 kHz; environmental sensors: ≤1 Hz)
Memory capacity (user data memory) 2MB
Communication BLE 4.0 / USB 2.0
Bluetooth frequency band 2400 – 2483.5 MHz
Transmission power (Bluetooth) 0 dBm
