3.6.1.1 Point Mode
The Point Mode setting determines whether:
• the transmitter is a burg point or fire point,
• Normally Open or Normally Closed contacts are used,
• the Internal and/or external contacts are used, and
• end of line resistors are used on the external contacts.
This applies to RF Transmitters that have external contacts and/or internal magnetic contacts (see Table 7).
External Contact
Inovonics
Transmitter
Mode
Normally
Open
Normally
Closed
End of Line Resistor
(use 2.2 K ¼ Watt)
Internal
Contact
Fire
Point
1
 
2

3
 
4

6
 
7
  
8
  
9
 
10
  
FA210 Reduced
Size Universal
FA210W
FA250 High Power
Universal
FA210BN
FA210WBN
11
 
5

FA210W &
FA210WBN
Reduced Size
“Wide-Gap”
Universal
12
 
Inovonics Transmitter Mode
FA113 Keyfob
(see Section 3.6.1.6 Programming the FA113 Keyfob, p. 22)
4
FA202 Photoelectric Smoke Detector 9
FA203S/D Necklace Pendant 4
FA204 Pendant 4
FA205S/FA205D Belt Clip/Loop 4
FA206 ALL 2
FA207 Glassbreak 4
FA209 Billtrap 4
FA216L/H Low Temperature/High Temperature 4
FA223S/D Single/Double Button Water Resistant Pendant 4
FA570 High Power Indoor Repeater
FA575 High Power Outdoor Repeater
4
Table 6: Recommended Mode Values
