16 en | Configuration DCN-D Conference Delegate Units
F.01U.265.631 | V1.0 | 2012.03 Installation and Operation manual Bosch Security Systems B.V.
7.3 Internal settings
The internal settings switches I and II (12) are located at the bottom side of the delegate unit.
Table 7.1 Internal settings
Figure 7.2 Internal settings switches
Switch: I Switch: II Internal settings
21 Microphone sensitivity. Default: 0 dB.
Refer to Section 7.3.1 Microphone sensitivity.
22 Channel/volume restore function. Default: disabled.
Refer to Section 7.3.2 Channel/volume restore function.
23 Headphones level reduction. Default: disabled.
Refer to Section 7.3.3 Headphones level reduction.
