28 en | Connecting the E2700 controller-drive tray to the hosts DSA E-Series (E2700)
2015.10 | V2 | DOC Installation manual Bosch Sicherheitssysteme GmbH
Host channels on the E2712 and E2712 controllers with no HIC – rear view
49002-07
1 2
1 HD mini-SAS native host channel 1 2 HD mini-SAS native host channel 2
Host channels on the E2712 and E2712 controllers with a two-port iSCSI HIC – rear view
1 2
iSCSI
Host
S
S
SL
S
A
Lnk Lnk
LnkLnk
Port 2Port 1
Ch 4 Ch 3
Drive Expansion
L
1 iSCSI host interface card channel 3 2 - iSCSI host interface card channel 4
