4 en | Table of contents DSA E-Series (E2700)
2015.10 | V2 | DOC Installation manual Bosch Sicherheitssysteme GmbH
11
Connecting the power cords 54
11.1 Things to know – AC power cords 54
11.2 Procedure – connecting AC power cords 54
12
Turning on the power and checking for problems in an E2700 controller-drive tray
configuration
55
12.1 Procedure –turning on the power to the storage array and checking for problems in a
E2700 controller-drive tray configuration
55
12.2 Things to know –LEDs on the E2712 controller-drive tray 56
12.3 Things to know – general behavior of the LEDs on the controller-drive tray 60
12.4 Things to know – service action allowed LEDs 62
12.5 Things to know –LEDs on the DE6600 drive tray 63
12.6 LEDs on the DE6600 drive drawers 66
12.7 LEDs on the DE6600 drives 67
12.8 General behavior of the LEDs on the drive trays 67
12.9 Things to know –seven segment display sequence code definitions on the E2700
controller-drive tray
69
12.10 Things to know –seven segment component failure identifications for the E2700
controller-drive tray
69
12.11 Things to Know – Lock-Down Codes for the Controller-Drive Tray 70
12.12 Things to know – seven-segment display use cases 72
12.13 Things to know – seven-segment display for the ESMs on the drive trays 74
13
Regulatory compliance statements 75
14
Trademark information 76
15
Additional documentation 77
