EV2000 Series Wallbox Charger Installation and Operation Manual|
11 |
en
9.0 System Code
Alarm Code Description
004001 System input voltage is higher than workable range ( > 305 volt)
004002 System input voltage is lower than workable range ( < 170 volt)
004003 System output voltage is higher than EV battery maximum voltage
004004 Request output current from EV is higher than present EVSE ability
004005 The temperature of air inlet or input contactor is higher than workable range ( > 60
degree C )
004006 The temperature of CCS combo charging plug is higher than workable range
REMA => ( > 85 degree C )
Phoenix => ( > 75 degree C )
004007 The air lter need to be replaced
004008 System fan is attenuated so that need to be replaced
004009 The self-test of system controller is failure
00400A Emergency button is pressed
00400B The user authorized by backend is failed
00400C The user authorized by EVSE itself is failed
00400D The temperature sensor of air inlet is broken
00400E The temperature sensor of input contactor is broken
00400F SPD trigger
004010 Output fuse at CCS side is broken
004011 Output fuse at CHAdeMO side is broken
004012 The temperature sensor of CCS combo charging plug is broken
004013 Yhe temperature of air inlet or input contactor is lower than workable range ( < - 40
degree C )
004014 User stops charging
004015 The plug-in times of CCS charging plug is more than 10000 times
004016 The plug-in times of CHAdeMO charging plug is more than 10000 times
004017 System is timeout if user doesn’t plug-in in 5 mnutes after authorized
004018 Charging time is up
004019 System data storage is not enough.
004021 Charging is remotely stopped by backend ofce
004022 Input voltage is drop
004023 System L1 input voltage is lower than workable range ( < 170 volt)
005001 Communication with CHAdeMO EV is broken
005005 Communication with CCS EV is broken
005006 Power rectier is broken
005007 Communication with CCS controller is broken
005008 Communication with aux. power module is broken
005009 Communication with relay control module is broken
00500C Communication with display module is broken
00500D Communication with RFID module is broken
00500E 3G module is not ready (module itself or SIM)
00500F WiFi module is not ready
006001
3G connection is disconnected from APN
