Alarm Code Description
006002 3G connection is disconnected from internet
006003 3G connection is disconnected from backend ofce
006006 WiFi connection is disconnected from backend ofce
006008 Ethernet connection is disconnected from internet
006009 Ethernet connection is disconnected from backend ofce
007001 Hardware component in power rectier is broken
007002 Input voltage of power rectier is higher than workable range
007003 Input voltage of power rectier is lower than workable range
007004 Output voltage is higher than workable range of power rectier
007006 The temperature of air inlet in power rectier is higher than workable range ( > 60 de-
gree C )
007008 The temperature of PFC is higher than workable range
007009 The temperature of PFC is lower than workable range
00700A The temperature of DCDC is higher than workable range
00700B The temperature of DCDC is lower than workable range
00700C The fan inside power rectier is broken
00700D Output o-ring diode is broken
00700E Isolation test failed
008003 5 volt for system controller is higher than workable range
008004 5 volt for other system modules is higher than workable range
008005 5 volt for CAN bus is higher than workable range
008006 12 volt for other system modules is higher than workable range
008007 12 volt for EV communication is higher than workable range
008008 24 volt for relay control is higher than workable range
008009 5 volt for system controller is lower than workable range
00800A 5 volt for other system modules is lower than workable range
00800B 5 volt for CAN bus is lower than workable range
00800C 12 volt for other system modules is lower than workable range
00800D 12 volt for EV communication is lower than workable range
00800E 24 volt for relay control is lower than workable range
008010 The output current of 5 volt for system controller is higher than workable range
008011 The output current of 5 volt for other system modules is higher than workable range
008012 The output current of 5 volt for CAN bus is higher than workable range
008013 The output current of 12 volt for other system modules is higher than workable range
008014 The output current of 12 volt for EV communication is higher than workable range
008015 The output current of 24 volt for relay control is higher than workable range
008016 The temperature of 12 volt for EV communication is higher than workable range
008017 The temperature of 5 volt for other system modules is higher than workable range
008018 The temperature of 24 volt for relay control is higher than workable range
008019 The ambient temperature of aux. power is higher than workable range
009001 GFD trigger
009002 The temperature of output diode is higher than workable range
009003 GFD pre-warning
00A001 Input contactor 1 is welding
