579604 | REV. C | June 2020
Bosch Automotive Service Solutions Inc.
EV2000 Series Wallbox Charger Installation and Operation Manual|
13
|
en
Alarm Code Description
00A002 Input contactor 1 is driven fault
00A003 Input contactor 2 is welding
00A006 The positive side of output relay for CCS charging is driven fault
00A007 The positive side of output relay for CHAdeMO charging is welding
00A008 The positive side of output relay for CHAdeMO charging is driven fault
00A009 The negative side of output relay for CCS charging is welding
00A00A The negative side of output relay for CCS charging is driven fault
00A00B The negative side of output relay for CHAdeMO charging is welding
00A00C The negative side of output relay for CHAdeMO charging is driven fault
00B001 The rmware update of aux. power module is failure
00B002 The rmware update of relay control module is failure
00B003 The rmware update of LCM module is failure
00B004 The rmware update of CCS charging module is failure
00B005 The rmware update of CHAdeMO charging module is failure
00B006 The rmware update of power converter module is failure
00C001 PLC module for CCS charging is broken
00C002 CCS proximity is disconnected
00C003 Stop charging by CCS EV
00D001 No charging permission come from CHAdeMO EV
00D002 Battery malfunction come from CHAdeMO EV
00D003 Battery incompatibility with CHAdeMO EV
00D006 Present output current is different from target current
00D007 Battery OTP come from CHAdeMO EV
00D008 Present output voltage is different from target voltage
00D009 Position shift alarm is come from CHAdeMO EV
00D00A EV other fault is come from CHAdeMO EV
00D00B CHAdeMO connector lock is broken
