FLEXIDOME multi 7000i Table of contents | en 3
Bosch Security Systems B.V.
Installation manual
2021-03 | 01 |
Table of contents
1
Safety 5
1.1 Safety message explanation 5
1.2 Safety precautions 5
1.3 Important safety instructions 5
1.4 Notices 6
2
Short information 7
3
System overview 8
3.1 Product description 8
3.2 Intended use 9
3.3 Using the camera 9
3.4 Operation with external systems 9
4
Planning information 10
4.1 Unpacking 10
4.2 Parts included 10
4.3 Preparation 11
4.4 Network and PoE+ 11
5
Installation 12
5.1 Installing the mounting plate 12
5.1.1 Installing the mounting plate without conduit 13
5.1.2 Installing the mounting plate with conduit (NDA-7051-CA) 13
5.2 Installing the camera base 15
5.2.1 Before the installation 15
5.2.2 Installation steps 16
5.2.3 Wiring the camera base 20
5.2.4 Connecting a wireless USB dongle 22
5.3 Setting the position of each of the four lenses 22
5.3.1 Panning each of the four lenses over the ring 23
5.3.2 Tilting each of the four lenses 23
5.3.3 Rotating each of the four lenses 24
5.3.4 Rolling each of the four lenses 25
5.4 Installing the camera dome cover 25
5.5 Optional mounting accessories 26
6
Configuration 30
6.1 Bosch Project Assistant 30
6.2 Browser connection 30
6.2.1 Establishing the network 30
6.2.2 Protected network 30
6.3 Bosch Video Client 30
6.4 Video Security Client 31
7
Troubleshooting 32
7.1 Resolving problems 32
7.2 Testing the network 32
7.3 Customer service 33
8
Maintenance 34
8.1 Cleaning 34
8.2 Repair 34
8.3 Reset 34
9
Decommissioning 36
