Page #9 background imageLoading...
Page #9 background image
FLEXIDOME multi 7000i | FLEXIDOME multi 7000i
IR
Operation via the browser | en 9
Bosch Security Systems B.V.
User manual
2021-04 | 01 |
3 Operation via the browser
3.1 Live page
After the connection is established, the Live page is initially displayed. It shows the live video
image on the right of the browser window. Depending on the configuration, various text
overlays may be visible on the live video image.
Other information may also be shown next to the live video image. The items shown depend
on the settings on the 'Live' functions page.
Connection
In the Connection group, you can configure the Stream option.
Video channel selection
Each video channel corresponds to one of the four imagers in the camera.
To view a video channel:
1. On the left side of the browser, expand the Connection group if necessary.
2. Click the Video drop-down arrow to see the options.
3. Select the video channel you wish to view.
Video stream selection
To view a live stream of the selected video channel:
1. On the left side of the browser, expand the Connection group if necessary.
2. Click the Stream drop-down arrow to see the options.
Select the stream you wish to view.
Digital I/O
Depending on the configuration of the unit, the alarm input and the output are displayed next
to the image. Expand the Digital I/O group if necessary.
The alarm symbol is for information and indicates the status of an alarm input:
The symbol lights when the input alarm is active.
The alarm output allows the operation of an external device (for example, a light or a door
opener).
To activate the output, click the checkmark symbol.
The symbol lights when the output is activated.
Recording status
The hard drive icon below the live camera image changes during an automatic recording.
The icon lights up and displays a moving graphic to indicate a running recording. If no
recording is taking place, a static icon is displayed.
Full-screen display
Click the full-screen icon to view the selected stream in full-screen mode; press Esc
on the keyboard to return to the normal viewing window.
Saving snapshots
Individual images from the displayed live video stream can be saved locally in JPEG format on
the computer's hard drive. The storage location depends on the configuration of the camera.
Click the photo camera icon to save a single image.
