Bosch GLM 50 C User Manual

-14-
Technical Data
Laser Measure GLM 50 C
Article Number
3601K72C10
Measuring range (typical): 6 in – 165 ft (0.15
– 50 m)
A
Measuring accuracy (typical)
±1/16 in (±1.5 mm)
B
Lowest indication unit ±1/32 in (0.1 mm)
Indirect Distance Measurement and Vial
Measuring range 0°–360° (4 x 90°)
Angle Measurement
Measuring range 0°–360° (4 x 90°)
Measuring accuracy (typical) ±0.2°
C/D
Lowest indication unit 0.1°
General
Operating temperature +14 °F to 113 °F
(-10 °C to 45 °C)
E
Storage temperature -4 °F to 158 °F
(-20 °C to 70 °C)
Relative air humidity, max. 90 %
Laser class
2
Laser type 635 nm, <1 mW
Laser beam diameter at 77 °F
(25 °C) approx.
– at 33 ft (10 m) distance
– at 165 ft (50 m) distance
4/11 in (9 mm)
1-3/4 in (45 mm)
Weight 0.22 lb (0.1 kg)
Dimensions 4.2 x 1.8 x 0.9 in
(106 x 45 x 24
mm)

Bosch GLM 50 C Specifications

General

Accuracy	±1.5 mm
Bluetooth Connectivity	Yes
Laser Diode	635 nm, <1 mW
Laser Class	2
Memory	30 measurements
Storage Temperature	-20°C to +70°C
Protection Class	IP54
Measuring Range	0.05 m to 50 m
Display	Color display with backlight
Power Source	2 x 1.5 V LR03 (AAA) batteries
Weight	0.1 kg
Automatic Deactivation	5 minutes
Units of Measurement	m/cm, ft/in
Battery Life	Approx. 10, 000 measurements
Operating Temperature	-10°C to +45°C
