Digital laser measure GLM 80 GLM 80+R 60
Automatic switch-off after approx.
– Laser 20s 20s
– Measuring tool (without measurement) 5min 5min
Weight according to EPTA-Procedure 01:2014 0.14kg 0.14kg
Dimensions 51 x 111 x 30mm 51 x 111 x 30mm
Protection rating IP 54 (dust and splash-proof) IP 54 (dust and splash-proof)
Measuring rail
Article number –
3 601 K79 000
Dimensions – 58 x 610 x 30mm
Battery Li-ion Li-ion
Rated voltage 3.7 V 3.7 V
Capacity 1.25 Ah 1.25 Ah
Number of battery cells 1 1
Individual measurements per battery charge approx. 25000
I)
25000
I)
A) For measurements from the front edge of the measuring tool, 100% reflectivity of the target (e.g. a white wall), weak backlighting and 25°C
operating temperature. In addition, a deviation influence of ± 0.05mm/m needs to be taken into account.
B) For measurements from the rear edge of the measuring tool, 10–100 % reflectivity of the target, strong backlighting and 25°C operating
temperature. In addition, a deviation influence of ± 0.29mm/m needs to be taken into account.
C) For measurements that use the back of the device as a reference, the max. measuring range amounts to ± 60°
D)
After calibration in accordance with figure H. Additional pitch error of ± 0.01°/degree up to 45°.
E) The width of the laser line depends on the surface characteristics and on the ambient conditions.
F) In continuous measurement mode, the max. operating temperature is +40 °C.
G) Only non-conductive deposits occur, whereby occasional temporary conductivity caused by condensation is expected.
H) At 25°C
I) For a new and charged battery without display illumination and sound.
The serial number (18) on the type plate is used to clearly identify your measuring tool.
Assembly
Battery charging
The battery can be charged from a USB port or USB power
supply (min. 500mA) by using the micro USB cable.
Recommendations for optimal handling of the battery
Only store the battery in the permitted temperature range
(see "Technical data"). Do not leave the battery in your car in
the summer, for example.
A significantly reduced operating time after charging indic-
ates that the battery has deteriorated and must be replaced.
Follow the instructions on correct disposal.
Operation
Start-Up
u Protect the measuring tool from moisture and direct
sunlight.
u Do not expose the measuring tool to any extreme tem-
peratures or variations in temperature. For example,
do not leave it in a car for extended periods of time. In
case of large variations in temperature, allow the measur-
ing tool to adjust to the ambient temperature before put-
ting it into operation. The precision of the measuring tool
may be compromised if exposed to extreme temperat-
ures or variations in temperature.
u Avoid substantial knocks to the measuring tool and
avoid dropping it. Always carry out an accuracy check
before continuing work if the measuring tool has been
subjected to severe external influences (see "Checking
accuracy and calibrating the grade measurement (see fig-
ureH)", page14) and (see "Accuracy check of the dis-
tance measurement", page14).
Switching on/off
u Never leave the measuring tool unattended when
switched on, and ensure the measuring tool is
switched off after use. Others may be dazzled by the
laser beam.
The following options are available for switching on the
measuring tool:
– Pressing the on/off button (8): The measuring tool is
switched on in the length measurement function. The
laser is not switched on.
– Pressing the measuring button (2): Measuring tool and
laser are switched on. The measuring tool will be in the
length measurement function. When the measuring tool is
inserted in the measuring rail (24), the grade measure-
ment function is activated.
1 609 92A 544 | (27.05.2019) Bosch Power Tools
