Bosch GLM 80 Original Instructions

English | 9
(26)
Tripod
B)
(27)
Laser viewing glasses
B)
(28)
Laser target plate
B)
A)
Press and hold a button to activate its additional function.
B)
Accessories shown or described are not included with the
product as standard.
Display elements
(a)
Measured value lines
(b) "ERROR" indicator
(c)
Result line
(d)
Digital spirit level/position of measured value list
entry
(e)
Indicator for measured value list
(f)
Measuring functions
Length measurement
Area measurement
Volume measurement
Continuous measurement
1
Indirect height measurement
1
2
Double indirect height measurement
1
Indirect length measurement
Timer function
Wall area measurement
Grade measurement
(g)
Battery charge indicator
(h)
Laser switched on
(i)
Reference level of measurement
(j)
Temperature warning
Technical data
Digital laser measure GLM 80 GLM 80+R 60
Article number
3 601 K72 3.. 3 601 K72 3..
Distance measurement
Measuring range (typical) 0.05–80m
A)
0.05–80m
A)
Measuring range (typical, unfavourable conditions) 35m
B)
35m
B)
Measuring accuracy (typical) ± 1.5mm
A)
± 1.5mm
A)
Measuring accuracy (typical, unfavourable conditions) ±2.5mm
B)
±2.5mm
B)
Smallest display unit 0.1mm 0.1mm
Indirect distance measurement and level
Measuring range –60° to +60° –60° to +60°
Grade measurement
Measuring range 0°–360° (4 x 90°)
C)
0°–360° (4 x 90°)
C)
Measuring accuracy (typical) 0.2°
D) E)
±0.2°
D) E)
Smallest display unit 0.1° 0.1°
General
Operating temperature -10°C to +50°C
F)
-10°C to +50°C
F)
Storage temperature -20°C to +50°C -20°C to +50°C
Permitted charging temperature range +5°C to +40°C +5°C to +40°C
Relative air humidity max. 90% 90%
Max. altitude 2000 m 2000 m
Pollution degree according to IEC61010-1 2
G)
2
G)
Laser class 2 2
Laser type 635 nm, < 1mW 635 nm, < 1mW
Laser beam diameter (at 25°C) approx.
– 10m distance 6mm
E)
6mm
E)
– 80m distance 48mm
E)
48mm
E)
Adjustment accuracy of the laser to the housing approx.
– Vertical ±2mm/m
H)
±2mm/m
H)
– Horizontal ±10mm/m
H)
±10mm/m
H)
Bosch Power Tools 1 609 92A 544 | (27.05.2019)

Bosch GLM 80 Specifications

General

Accuracy	± 1.5 mm
Laser Class	2
Laser Diode	635 nm, < 1 mW
Measuring Accuracy (typical)	± 0.2°
Measurement Time, typical	< 0.5 s
Measurement Time, max.	4 s
Automatic Deactivation	5 min
Memory Capacity (Values)	20
Dust and Splash Protection	IP54
Tripod Thread	1/4"
Dimensions	111 x 51 x 30 mm
Measuring Range	0.05 – 80 m
Battery Life	up to 25, 000 measurements
Display	Illuminated
Operating Temperature	-10 – +50°C
Storage Temperature	-20°C to +70°C
