Safety Instructions
All instructions must be
read and observed in order
for the measuring tool to
function safely. The safe-
guards integrated into the
measuring tool may be compromised if the measuring
tool is not used in accordance with these instructions.
Never make warning signs on the measuring tool unre-
cognisable. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE AND INCLUDE THEM WITH THE MEASURING
TOOL WHEN TRANSFERRING IT TO A THIRD PARTY.
u Warning! If operating or adjustment devices other
than those specified here are used or other proced-
ures are carried out, this can lead to dangerous expos-
ure to radiation.
The measuring tool is delivered with a warning label
(marked in the illustration of the measuring tool on the
graphics page with number (20)).
Laser Radiation
Do not stare into beam
Class 2 laser product
u If the text on the warning label is not in your native
language, cover it with the label supplied, which is in
your language, before initial commissioning.
Do not direct the laser beam at persons or
animals and do not look directly into the
laser beam or at its reflection. Doing so
could lead to blindless, or could cause acci-
dents or damage to the eyes.
u If laser radiation hits your eye, you must close your
eyes and immediately turn your head away from the
beam.
u Do not make any modifications to the laser equip-
ment.
u Do not use the laser goggles as protective goggles.
The laser goggles make the laser beam easier to see; they
do not protect you against laser radiation.
u Do not use the laser goggles as sunglasses or while
driving. The laser goggles do not provide full UV protec-
tion and impair your ability to see colours.
u Have the measuring tool serviced only by a qualified
specialist using only original replacement parts. This
will ensure that the safety of the measuring tool is main-
tained.
u Do not let children use the laser measuring tool unsu-
pervised. They could accidentally dazzle someone.
u Do not use the measuring tool in explosive atmo-
spheres which contain flammable liquids, gases or
dust. Sparks may be produced inside the measuring tool,
which can ignite dust or fumes.
Protect the measuring tool against heat,
e.g. including prolonged sun exposure, fire,
water, and moisture. Danger of explosion.
Product Description and
Specifications
Intended Use
The measuring tool is intended for measuring distances,
lengths, heights, clearances and inclines, and for calculating
areas and volumes.
The measuring tool is suitable for indoor and outdoor use.
Product features
The numbering of the product features refers to the diagram
of the measuring tool on the graphics page.
(1)
Display
(2)
Measuring button
(3)
Button for grade measurement/calibration
A)
(4)
Button for changing function/basic settings
A)
(5)
Minus button
(6)
Button for results/timer function
A)
(7)
Button for list of measured values/saving constant
A)
(8)
Button for memory deletion/switching on or off
A)
(9)
Measuring pin
(10)
Reference level selection button
(11)
Plus button
(12)
Button for distance, area and volume measurement
(13)
Charging socket cover
(14)
Socket for charging connector
(15)
Carrying strap lug
(16)
Laser beam output
(17)
Reception lens
(18)
Serial number
(19)
1/4" thread
(20)
Laser warning label
(21)
Charging connector
(22)
Micro USB cable
(23)
Protective bag
(24)
Measuring rail
B)
(25)
Locking lever for measuring bar
B)
