60 en | Installing Roof Parapet and Pipe Mounts VG4 Modular Camera Series
F.01U.216.010 | 8.0 | 2011.02 Installation Manual Bosch Security Systems, Inc.
3.7.1 Wiring for Multiple AutoDomes
To wire multiple AutoDomes in a series, or “daisy chaining,” you must apply a terminating
resistor to the last dome of the series. The Interface Board is supplied with a 100 ?
terminating resistor located between the Biphase terminals C- and C+ (pins 1 and 2) of the
P105 control connector (see item 5 in Figure 3.10 above). Remove the resistor from all but the
last AutoDome Interface Board. The maximum number of AutoDomes that can be daisy
chained is four (4).If using the RS485 protocol for control, switch the terminating resistor
from the Biphase C+ and C- terminals to the RxD+ and TxD- terminals (pins 4 and 5) of the
P105 control connector for the last dome (see item 6 in Figure 3.10 above).
3.7.2 Connecting Wires to the Pipe Interface Board
The Pipe Interface Board contains all of the connectors for control, data, image, and power
wires. Follow the procedures below to make the proper connections.
1. Attach a BNC connector to the video coax cable and connect it to its mating connector
J102 on the Pipe Interface Board. If using UTP for video or Ethernet, attach an RJ45
connector plug to the e UTP cable and connect the plug to its mating connector J101 on
the Pipe Interface Board.
Ref. Description Connector Wire Gauge Pin Description
1 Pipe Interface Module
2 Video Coax In J102
3 6-pin Connector Alarms In (3-7) P103
4 4-pin Connector Alarms Out (1-3) P102
5 100 ? Resistor P105
6 Data In/Out P105 AWG 26-16 1 Biphase (C-)
2Biphase (C+)
3 Earth Ground
4RxD +
5 TxD -
6 Signal Ground
7 Alarms In (EOLR Supervised, 1-2) P104 AWG 26-16 7 Ground
6 Alarm 2
5 Alarm 1
4 Earth Ground
8 Relay Output P104 AWG 26-16 3 Normally Closed
2 Common
1 Normally Open
9 Dome Power P101 AWG 18-14 3 Dome 24 VAC
2 Earth Ground
1Dome 24 VAC
10 Heater Power P107 AWG 18-14 2 Heater 24 VAC
1 Heater 24 VAC
11 RJ45 Ethernet or UTP Video J101
12 To AutoDome
WARNING!
Use a 24 VAC Class 2 power supply only.
WARNING!
Do not connect the RJ45 connector unless using UTP video or Ethernet. This connection
causes video distortion.
