4 Installing the In-Ceiling Mount
4.1 Unpacking
This equipment should be unpacked and handled with care. If an item appears to have been
damaged in shipment, notify the shipper immediately.
Verify that all the parts listed in the product's Parts List below are included. If any items are
missing, notify your Bosch Security Systems Sales or Customer Service Representative. See
See Section 1.5 for Customer Support and Service contact information.
The original packing carton is the safest container in which to transport the unit and must be
used if returning the unit for service. Save it for possible future use.
4.1.1 Parts List
The following table lists the parts included with the In-ceiling mount packages.
In-ceiling Mount Kit
Quantity Item Part Number
1 Interface Box VG4-S-BIM
1 In-ceiling Housing
(COMMS and CPU modules installed)
F01U010500
1 Camera Module VG4-MCAM-XXX
1 Bracket Assembly LTC 9349MK
1 Clear Bubble with white and black trim rings, or
Tinted Bubble with white and black trim rings
VG4-SBUB-CCL
VG4-SBUB-CTI
To Next Page
