46
Hot-waterfeedrouteHot-waterfeedroute
Hot-waterfeedrouteHot-waterfeedroute
Hot-waterfeedroute
KM3211WHKM3211WH
KM3211WHKM3211WH
KM3211WH
．．
．．
．
KM3211WHQKM3211WHQ
KM3211WHQKM3211WHQ
KM3211WHQ
Part Nos. Part Names Order Nos. Q'ty／unit Note
400 Heat exchanger EAC SET-AS SBN7205 1 012, 109, 401, 402, 428, 434
also replace
401 Thermal fuse DHN SET-V SBA7398 1
402 Thermal fuse fastener CXD CXDH003 5
405 Water inlet coupling DJP DJPD012 2 For KM3211WHQ 420, 434 also replace
406 Thermal fuse cover DHN DHNA014 2
407 Freeze preventive heater Q DJW SET-V SKA7037 1
408 Heater fastener EHK EHKH001 1
409 Remaining flame safety device 120 DJP DJPH002 1
410 Water flow servo set 2 DZT DZTD011 1 434 also replace
411 Heat exchanger thermistor-300 BWC BWCD098 1 412 also replace
412 O-ring P4C 1323709 5 For KM3211WH
O-ring P4C 1323709 6 For KM3211WHQ
413 Thermistor holding plate ALS ALSD088 5 For KM3211WH
Thermistor holding plate ALS ALSD088 6 For KM3211WHQ
414 O-ring P20C 3059502 1
417 Water flow servo set 1 DZT DZTD010 1 434 also replace
418 Freeze preventive heater 3 DJW DJWH003 3 For KM3211WH
Freeze preventive heater 3 DJW DJWH003 4 For KM3211WHQ
420 O-ring P22C 7573308 1 For KM3211WH
O-ring P22C 7573308 3 For KM3211WHQ
421 Hot-water feed pipe DHN DHND010 1
422 Bypass pipe EAC EACD003 1
423 Hot-water thermistor-300 BWC BWCD096 1 412 also replace
424 Water flow sensor set 3 DUV DUVD019 1 428, 434 also replace
425 Water inlet thermistor-300 BWC BWCD097 1 412 also replace
427 Water outlet magnetic sensor BWC BWCD090 1
428 O-ring P12.5C 3359808 2 For KM3211WH
O-ring P12.5C 3359808 8 For KM3211WHQ
429 Branching fittingSET DHN DHND018 1 For KM3211WHQ 420, 428 also replace
431 Water inlet pipe EAC EACD001 1 For KM3211WH
433 Quick fastener 13-22 SAD6537 1 For KM3211WH
Quick fastener 13-22 SAD6537 6 For KM3211WHQ
434 O-ring P16C 3223302 7
435 Shut-off cock AXG AXGD089 2 For KM3211WH 412 also replace
Shut-off cock AXG AXGD089 3 For KM3211WHQ 412 also replace
437 Water inlet fitting 20ASET EAC EACD006 1 For KM3211WH 434 also replace
Water inlet fitting 20ASET EBA EBAD003 1 For KM3211WHQ 428, 434 also replace
438 Water filter (SUS) EGB EGBD032 1 For KM3211WH
Water filter DTJ DTJD005 1 For KM3211WHQ
439 O-ring 16DF BRQ BRQL008 1
440 Water filter cap DTJ DTJD006 1 439 also replace
441 Drain cock CRU CRUD003 1 For KM3211WH 442 also replace
Drain cock CRU CRUD003 2 For KM3211WHQ 442 also replace
442 Hot-water resistant O-ring P3 SAD6633 1 For KM3211WH
Hot-water resistant O-ring P3 SAD6633 2 For KM3211WHQ
443 Mixing coupling EAC EACD007 1 434, 455 also replace
444 Mixing body EAC EACD013 1 420, 434, 453, 455 also replace
445 Mixing cylinder BWC BWCD035 1 453, 455 also replace
446 QMF safety valve A(S) SAA2811 1 447 also replace
447 Hot-water resistant O-ring P9 SAD6635 1
448 Return fitting 15A SET EAD EADD010 1 For KM3211WHQ 420, 477 also replace
449 Water inlet fitting cover CRU CRUD005 1 For KM3211WHQ
450 O-ring JASO 2023 type1 A SAA6433 1 For KM3211WHQ
451 Water filter SUS DMM DMMD002 1 For KM3211WHQ
452 Hot-water outlet fitting HGH HGHD101 1 414, 442 also replace
453 O-ring P11C 1326503 1
454 Quick fastener 12.7 6340202 1
455 O-ring JASO 2026 type4 C SAA6483 1
456 Quick fastener 16A 6340300 6 For KM3211WH
Quick fastener 16A 6340300 7 For KM3211WHQ
458 Water flow sensor SET1 DUV DUVD017 1 428, 434 also replace
459 Pump vibration proof rubber ALS ALSD058 4 For KM3211WHQ
460 Pump foot DAN DANA012 1 For KM3211WHQ
