Bosch KM3211WH - Page 47

47
Hot-waterfeedrouteHot-waterfeedroute
Hot-waterfeedrouteHot-waterfeedroute
Hot-waterfeedroute
KM3211WHKM3211WH
KM3211WHKM3211WH
KM3211WH
．．
．．
．
KM3211WHQKM3211WHQ
KM3211WHQKM3211WHQ
KM3211WHQ
Part Nos. Part Names Order Nos. Q'ty／unit Note
462 Water flow sensor SET1 DUV DUVD018 1 For KM3211WHQ 428, 434 also replace
463 Magnetic sensor BWC BWCD093 1
464 Magnetic sensor for circulation BWC BWCD092 1 For KM3211WHQ
468 Freeze Protection Thermostat BVU BVUH002 2
470 Conduit 86 DZT DZTJ008 1
471 Waterproof cover CZL CZLD041 2
472 Servo motor cable conduit (86) DZT DZTJ009 1
475 Pump HK DHN DHND026 1 For KM3211WHQ 428 also replace
476 Shut-off valve SET DSC DSCD028 1 For KM3211WHQ 420 also replace
477 O-ring P14C 1326708 1 For KM3211WHQ
480 Water inlet pipe EAD EADD001 1 For KM3211WHQ
481 Return pipe EAD EADD006 1 For KM3211WHQ
482 Pump comes out of pipe EAD EADD008 1 For KM3211WHQ
483 Dummy heater 240V DJW DJWH004 1 For KM3211WH
Dummy heater 240V DJW DJWH004 2 For KM3211WHQ
484 Heater fastener M AJB AJBL002 1 For KM3211WH
Heater fastener M AJB AJBL002 4 For KM3211WHQ
485 Freeze preventive heater2 DJW DJWH002 2 For KM3211WHQ
506 Cross recessed round-head machine screw M4X8 For KM3211WHQ SUS430
507 Cross recessed truss P TIGHT screw 4X10 SUS305
508 Cross recessed round-head P TIGHT screw 4X14 SUS305
509 Cross＆straight recessed round-head collar type3 S TIGHT tapping screw 4X8 SUS410
510 Cross＆straight recessed type3 S TIGHT tapping screw 4X8 SUS410
511 Cross recessed round-head P TIGHT screw 4X14 SUS410
512 Cross recessed round-head type3 EVERTIGHT tapping screw 4X8 For KM3211WHQ SWRM chromate
