40 | Troubleshooting LV Heat Pump Series
LV Heat Pump Series8 733 944 336 (2016/09) Subject to change without prior notice
TEMPERATURE /PRESSURE TABLE
Table 13: OPERATING DATA
COOLING HEATING
MODEL
ENTERING
WATER TEMP, ˚F
WATER FLOW
GPM
SUCTION
PRESSURE
PSIG
DISCHARGE
PRESSURE
PSIG
WATER TEMP
RISE, ˚F
AIR TEMP
DROP, ˚F
SUCTION
PRESSURE
PSIG
DISCHARGE
PRESSURE
PSIG
WATER TEMP
DROP, ˚F
AIR TEMP
RISE, ˚F
LV007
30˚
1.4 65-80 282-344 6-7 14-17
1.9 73-89 294-359 3-4 15-18
40˚
1.4 106-129 146-178 17-21 18-22 80-98 299-365 7-9 16-20
1.9 102-124 133-162 10-13 19-23 89-108 311-380 4-5 17-21
50˚
1.4 115-141 180-220 17-20 17-21 95-116 315-385 9-11 19-23
1.9 111-135 163-200 10-12 18-23 105-128 329-402 5-7 20-24
60˚
1.4 124-152 213-261 16-19 17-21 109-133 332-406 11-13 21-26
1.9 120-146 194-237 10-12 18-22 121-148 346-423 6-8 22-27
70˚
1.4 134-163 247-302 15-19 17-20 124-151 349-427 12-15 23-28
1.9 128-157 225-275 9-11 18-21 138-168 364-444 7-9 25-30
80˚
1.4 143-175 281-343 14-18 16-20 138-169 366-447 14-17 26-31
1.9 137-168 255-312 9-11 17-21 154-188 381-466 8-10 27-33
90˚
1.4 152-186 315-385 14-17 16-19 153-187 383-468 16-19 28-34
1.9 146-179 286-350 8-10 17-20 170-208 399-487 9-12 29-36
100˚
1.4 161-197 349-426 13-16 15-19
1.9 155-190 317-387 8-10 16-20
LV009
30˚
1.8 91-111 251-307 5-6 21-25
2.4 95-116 256-313 3-4 22-26
40˚
1.8 112-137 144-176 14-17 22-27 107-130 267-327 6-7 24-29
2.4 106-130 137-167 10-12 23-28 112-137 273-333 4-5 25-30
50˚
1.8 116-142 177-217 13-16 21-26 123-150 284-347 7-9 27-33
2.4 111-135 169-206 9-12 22-27 129-158 289-353 5-6 28-34
60˚
1.8 121-148 211-258 13-16 21-26 139-170 300-366 8-10 30-37
2.4 115-140 200-245 9-11 22-27 146-179 306-374 6-7 32-39
70˚
1.8 126-154 245-299 13-15 20-25 156-190 316-386 9-12 33-41
2.4 119-146 232-284 9-11 21-26 163-200 322-394 7-8 35-43
80˚
1.8 130-159 278-340 12-15 20-24 172-210 332-406 11-13 36-44
2.4 124-151 264-323 9-11 21-26 180-220 339-414 8-9 38-47
90˚
1.8 135-165 312-381 12-15 19-24 188-230 349-426 12-15 39-48
2.4 128-157 296-362 9-10 20-25 197-241 355-434 8-10 41-51
100˚
1.8 140-171 345-422 12-14 19-23
2.4 133-162 328-401 8-10 20-24
