WATERSIDE PRESSURE DROP TABLE
Table 14:
Model
Water Flow Rate
(GPM)
Water Side Pressure Drop with out
Internal Valve (PSI)
Water Side Pressure Drop with Internal Valve (PSI)
LV007
1.0
0.3 0.5
2
1.1 1.8
3.0
2.3 3.8
LV009
1.0
0.5 0.6
2.0
1.7 2.3
3.0
3.5 5.0
LV012
1.5
1.0 1.4
2.5
2.6 3.6
3.5
4.8 6.7
LV015
2.0
1.9 2.5
3.0
3.9 5.3
4.0
6.5 9.1
LV018
2.5
1.1 2.1
4.0
2.7 5.2
5.0
4.0 8.0
LV024
3.0
1.7 2.0
4.0
2.8 3.4
6.0
5.8 7.2
LV030
4.0
2.0 2.6
6.0
4.2 5.6
8.0
7.0 9.6
LV036
4.5
1.6 2.4
6.0
2.6 4.0
9.0
5.4 8.6
LV041
5.0
2.0 3.0
8.0
4.6 7.2
11.0
8.2 13.1
LV042
5.0
2.0 3.0
8.0
4.6 7.2
11.0
8.2 13.0
LV048
6.0
0.8 1.4
8.0
1.4 2.5
12.0
2.8 5.4
LV060
7.5
1.4 2.4
10.0
2.3 4.1
15.0
4.8 8.8
LV070
9.0
2.0 3.4
12.0
3.4 5.9
18.0
7.0 12.7
All values based upon pure water at 70° F.
