Fan Motor Options | 27LV Heat Pump Series
8 733 905 683 (2016/09)LV Heat Pump Series
FAN MOTOR OPTIONS
Permanent Split Capacitor Motors (PSC)
The standard motor for all LV series heat pumps is a PSC
motor. For all models other than 575 V units, the
supplied motor is a three speed motor. 575 V motors are
single speed. If a speed change is required, follow the
instructions below:
1. Disconnect power to the heat pump.
2. For units with leaded motors, remove the front
access cover.
3. Remove the fan speed wire from the fan relay. Clip
the ¼” quick connect from the lead and cap the
unused lead.
4. Uncap the desired fan speed wire and terminate
with a ¼” quick connect. Connect to the fan relay.
5. If the motor is a 460 V motor and the speed is
changed from high to medium or low, connect the
high speed motor lead to the orange intermediate
winding lead instead of simply capping it.
Refer to the PSC motor performance tables for heat
pump blower performance with the PSC motor option.
Table 7: PSC Motor Performance Data
Model
Fan
Speed
Rated
Airflow
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20
LV-007
Low 370 340 295 250 - ---- ---
Med
300 390 360 330 300 260 ---- ---
Hi
410 380 350 315 280 210 - -- ---
LV-009
Low 370 340 295 250 - -------
Med
390 360 330 300 260 -------
Hi
350 410 380 350 315 280 210 - -----
LV-012
Low 300 290 290 300 - -------
Med
380 380 360 330 290 -------
Hi
400 420 400 380 360 340 320 - -----
LV-015
Low 500 450 400 ------ ---
Med
560 520 480 430 400 -------
Hi
500 700 650 600 550 500 450 400 -- ---
LV-018
Low 630 590 560 ------ ---
Med
650 810 790 760 730 680 590 - -----
Hi
1010 970 920 870 800 680 530 - ---
LV-024
Low 650 610 570 540 510 -------
Med
830 820 800 770 720 620 - -- ---
Hi
850 1050 1000 950 910 840 710 570 - ---
LV-030
Low 740 730 700 660 610 -------
Med
830 810 770 730 680 620 - -- ---
Hi
950 1000 950 900 830 750 698 630 - ---
LV-036
Low 1290 1250 1200 1150 1080 1000 - -- ---
Med
1410 1350 1290 1220 1150 1060 900 -----
Hi
1200 1500 1440 1370 1290 1210 1120 1000 900 - --
-
