Wiring Diagrams | 49LV Heat Pump Series
8 733 905 683 (2016/09)LV Heat Pump Series
WIRING DIAGRAMS
Figure # 19
UPM STATUS LED - BLINK CODES
1
HIGH PRESSURE FAULT
2 LOW PRESSURE FAULT
3 CONDENSER FREEZE CONDITION
4 CONDENSATE OVERFLOW FAULT
5
BROWN OUT FAULT
6 EVAPORATOR FREEZE CONDITION
BLK (HI)
BLU (MED)
RED (LOW)
FOR REFERENCE ONLY Actual unit wiring may
vary from this example. Always refer to the wiring
diagram attached to the unit.
To Next Page
