| 45LV Heat Pump Series
8 733 905 683 (2016/09)LV Heat Pump Series
OPERATING DATA
COOLING HEATING
MODEL
ENTERING
WATER TEMP,
˚F
WATER FLOW
GPM
SUCTION
PRESSURE
PSIG
DISCHARGE
PRESSURE
PSIG
WATER TEMP
RISE, ˚F
AIR TEMP
DROP, ˚F
SUCTION
PRESSURE
PSIG
DISCHARGE
PRESSURE
PSIG
WATER
TEMP DROP,
˚F
AIR TEMP
RISE, ˚F
LV060
30˚
8 68-84 256-313 5-7 19-23
12 73-89 261-319 4-5 20-25
40˚
8 113-138 173-212 18-22 19-23 81-99 277-339 7-8 22-26
12 110-134 162-198 12-14 20-24 86-105 283-346 5-6 23-28
50˚
8 116-142 207-253 17-21 19-23 93-114 299-365 8-9 24-29
12 112-137 193-236 12-14 19-24 99-121 305-373 6-7 25-31
60˚
8 118-145 240-293 17-21 18-23 106-129 321-392 9-11 26-32
12 115-140 224-274 11-14 19-23 113-138 327-400 7-8 28-34
70˚
8 121-148 273-334 17-21 18-22 118-145 342-418 10-12 29-35
12 117-143 255-312 11-14 19-23 126-154 349-427 8-9 30-37
80˚
8 123-151 307-375 16-20 18-22 131-160 364-444 11-14 31-38
12 120-146 287-350 11-13 19-23 139-170 371-454 8-10 33-40
90˚
8 126-154 340-416 16-20 18-22 143-175 385-471 12-15 33-41
12 122-149 318-388 11-13 18-22 152-186 393-480 9-11 35-43
100˚
8 128-157 373-456 16-19 17-21
12 125-152 349-426 11-13 18-22
LV070
30˚
12 68-84 256-313 5-7 19-23
16 73-89 261-319 4-5 20-25
40˚
12 117-143 182-222 15-19 21-26 81-99 277-339 7-8 22-26
16 114-139 170-208 11-14 22-27 86-105 283-346 5-6 23-28
50˚
12 120-147 215-263 15-18 20-25 93-114 299-365 8-9 24-29
16 117-143 201-246 11-14 21-26 99-121 305-373 6-7 25-31
60˚
12 123-150 248-304 14-17 20-24 106-129 321-392 9-11 26-32
16 119-146 232-284 11-13 21-25 113-138 327-400 7-8 28-34
70˚
12 126-154 282-344 14-17 19-24 118-145 342-418 10-12 29-35
16 122-149 263-322 10-13 20-25 126-154 349-427 8-9 30-37
80˚
12 129-157 315-385 13-16 19-23 131-160 364-444 11-14 31-38
16 125-153 294-360 10-12 19-24 139-170 371-454 8-10 33-40
90˚
12 132-161 348-426 13-16 18-22 143-175 385-471 12-15 33-41
16 128-156 326-398 10-12 19-23 152-186 393-480 9-11 35-43
100˚
12 134-164 382-466 12-15 17-21
16 131-160 357-436 9-11 18-22
