Connect the yellow/green wire of the camera to the system
earth of the installation to ensure correct safety and EMC/RFI
protection.
Network (and PoE power)
Connect the camera to a 10/100 Base-T network:
– Use STP Category 5e cable with RJ45 connectors (the
camera network socket is Auto MDIX compliant).
– Power is supplied to the camera via the Ethernet cable
compliant with the Power-over-Ethernet standard.
Notice!
Use only PoE approved devices.
Power-over-Ethernet can be connected at the same time as a
12 VDC power supply. If auxiliary power (12 VDC) and PoE is
applied simultaneously, the camera selects PoE and shuts off
the auxiliary input.
Auxiliary power
Connect a SELV-LPS or a SELV Class 2 power supply with a
rated supply voltage of 12 VDC as follows:
– Cut back 7 mm (0.28 in) of insulation.
– Connect the power wires (red+ , brown-) to the external
power supply.
Caution!
Use only a +12 VDC power supply as an auxiliary power source.
The auxiliary power supply unit must be isolated from earth.
Alarm
Use the stranded and solid wires with maximum diameter AWG
22-28; only cut back 5 mm (0.2 in) of insulation.
5.3.3
5.3.4
5.3.5
FLEXIDOME IP starlight
7000 VR
Installation | en 15
Bosch Security Systems 2016.06 | v1.0 | AM18-Q0710
