Axial piston variable motor | A6VM series 71
Dimensions size 85
33
Dimensions [inch (mm)]
▼ Location of working ports on port plates (view Z)
2 SAE working port
A and B at side,
opposite
1 SAE working port
A and B at rear
2 SAE working port
A and B at side, opposite
only HZ7, EZ7/8
1 SAE working port
A and B at rear
only HZ7, EZ7/8
B
A
6.46 (164)
B
A
6.97 (177)
2.13
(54)
2.13
(54)
AB
6.46 (164)
B
A
6.97 (177)
2.13
(54)
2.13
(54)
▼ Splined shaft SAEJ744
S9 ‒ 1 1/2in 17T 12/24DP
1)
2.44 (62)
DIA4.33 (DIA110)
2.13 (54)
7/16-14UNC-2B
2)
1.10
(28)
DIA1.97
(DIA50)
1.73 (44)
0.37
(9.5)
1) Involute toothing acc. to ANSI B92.1a, 30° pressure angle, flat root,
side fit, tolerance class 5
2) Thread according to ASME B1.1
